Metal Roof Tiles Charcoal Roof Tile

Product number
DE92020
An alternative to our felt shingles is metal roofing sheets. These have a life expectancy of at least 20 years. Easy to fit and give the impression of traditional roof tiles. Quick to fit and very light at only 6kg / m.sq. Only suitable for Apex Roofs.
dakpan_board_aquapan_antraciet_89_x_118_cm
dakpan_board_aquapan_antraciet
gadero_meppen_34
gadero_meppen_36
dakpanplaat_aquapan_dakbedekking_2
aquapan_antraciet_grijs_sfeer
dakpanplaat_aquapan_dakbedekking_9
dakpanplaat_aquapan_dakbedekking_10
aquapan_dakplaten_plaatsen
40x9996_14_s04
unnamed_104
dakpanplaat_aquapan_dakbedekking
model_Metalrooftiles_darkroof
model_Metal_Roof_Tiles_Red
model_metal_bargeboards_01
model_Metal_Ridge_Tile_01
model_metal_roof_tiles_end_cap_01
model_metal_roof_tiles_installation
model_metal_screws_roof_tiles_01
model_metal_roof_sheets
model_metal_roof_sheeting
model_Metal_roof_tiles_01
Per piece

26.94

incl. vat

279 pieces in stock
2 to 3 weeks
Details
Length
113,5 cm
  • Rated on Trustpilot with an 4.3/5
  • Unbeatable Industry Knowledge
  • Fast delivery in the UK

Specifications

Material
Steel
Length
113,5 cm

Metal Roof Tiles Charcoal Roof Tile

Metal Roof Tiles are a very viable alternative to felt tiles, these will last for at least twenty years, quick and easy to install and look like traditional tiles.

Suitable for Apex roofs only. These are NOT suitable for Flat or Pyramid roofs.

FEATURES OF OUR METAL ROOFING SHEETS:

  • Aluminium Roofing Panels with Zinc coating finished with stone granules.

  • Fit 35 tiles at the same time

  • Granulated, Rough Surface

  • Always fit with no cutting required

  • Old or new roof with a minimum pitch of 10 degrees

  • Light, Strong and Durable

  • Immediate Waterproofing

  • Sound absorbing finish stone granules

  • High resistance to aggressive atmospheric influences

  • No need to a reinforced roof structure

  • No waste

  • Apply directly to old roofing without the need of removing it first.

  • Two colours available - Red and Black

  • Only suitable for Apex Roofs


These are universal roofing sheets and will fit any roof, not just our log cabins or Larch buildings. Each sheet contains five tiles in width and seven tiles in height. Tiles are overlapped without the need for cutting. Very fast and easy to install with no waste. These are NOT suitable for flat roofs

COMPONENTS:
Metal Roof Sheets - 89cm x 118cm (0.86m.sq)
Ridge Capping pieces 91cm (working length 81cm)
End Caps for the Ridge
Barge board Overlap 91cm (working length 81cm)
Self tapping screws with EPDM seal. 40 Pieces per pack. (Six needed per sheet)

HOW MUCH DO YOU NEED?
Metal Roof Plates - calculate as follows:

Measure the total width and length of the roof to find the area in meters and then divide by 0.86 - round up this figure for the number of metal roof panels needed.
Example:

Roof boards are 2.37m in length
Roof length is 4.25m
2.37 x 4.25 = 10.07
To find the number of panels divide this by 0.86 (useable dimension of a panel)
10.07 / 0.86 = 11.70 - Therefore 12 panels are required
Remember this is ONE side of the roof so the total building will need 24 metal roof panels for both sides.

METAL ROOF BARGE BOARDS CALCULATION:
Roof boards length in meters and divide by 0.81. Round this up and multiply by four to account for all sides.

METAL RIDGE CAPPING CALCULATION:
Measure the length of the ridge in meters and divide by 0.81. Round this up for the number required.
End Caps - Each roof will require two end caps for the ridge pieces.

Screws: Each self tapping Screw pack contains 40 screws. Nine screws are required per plate including barge boards and ridge pieces. These screws are 20mm in length.
